MV kabeli
IEC 60502 ga muvofiq N2XSY N2XSRY bir yadroli o'rta kuchlanish kabellari
1.ILOVALAR
Bir yadroli kabellar nominal kuchlanish Uo/U 1,8/3KV dan 26/35KV gacha va chastotasi 50Hz bo'lgan elektr energiyasini taqsimlash uchun mo'ljallangan.
Ular asosan elektr ta'minoti stansiyalarida, bino ichida va kabel kanallarida, ochiq havoda, er osti va suvda, shuningdek, sanoat tarmoqlari, kommutatorlar va elektr stantsiyalari uchun kabel novdalariga o'rnatish uchun javob beradi.
|
|
|
2.STANDART
IEC 60502 1-qism (1,8/3KV); IEC 60502 2-qism (3,6/6KV dan 18/30KV gacha)
3.QURILISh
|
|
|
|
Dirijyor |
IEC 60228 1 yoki 2 sinfiga mos keladigan oddiy tavlangan mis yoki alyuminiy. |
|
Supero'tkazuvchilar ekrani |
Supero'tkazuvchilar ekrani barcha havo bo'shliqlarini istisno qilish uchun izolyatsiyaga mahkam bog'langan metall bo'lmagan, yarim o'tkazuvchan birikmaning ekstrude qilingan qatlamidan iborat. Supero'tkazuvchilar ekrani ham PVX, ham EPR/HEPR izolyatsiyali 1,8/3KV va 3,6/6KV kabellar uchun kerak emas. |
|
Izolyatsiya |
Izolyatsiya 1,8/3KV va 3,6/6KV kabellar, o'zaro bog'langan polietilen birikma (XLPE) yoki etilen propilen kauchuk (EPR/HEPR) uchun mo'ljallangan polivinilxloriddan (PVX) iborat. |
Jadval 1. XLPE yoki EPR/HEPR izolyatsiyasining izolyatsiyasining qalinligi
|
Nom. Ko‘ndalang kesim maydoni |
Nominal kuchlanishdagi izolyatsiya qalinligi |
|||||||||
|
1,8/3KV (Um=3,6KV) |
3,6/6KV (Um=7,2KV) |
6/10KV (Um=12KV) |
8,7/15KV (Um=17,5KV) |
12/20KV (Um=24KV) |
18/30KV (Um=36KV) |
21/35KV (Um=42KV) |
26/35KV (Um=42KV) |
|||
|
mm% 5e2 |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
mm |
||
|
|
XLPE% 2fEPR |
XLPE |
EPR |
XLPE% 2fEPR |
XLPE% 2fEPR |
XLPE% 2fEPR |
XLPE% 2fEPR |
XLPE% 2fEPR |
XLPE% 2fEPR |
|
|
Ekrandan chiqarilmagan |
Ekranlangan |
|||||||||
|
10 |
2.0 |
2.5 |
3.0 |
2.5 |
- |
- |
- |
- |
- |
- |
|
16 |
2.0 |
2.5 |
3.0 |
2.5 |
3.4 |
- |
- |
- |
- |
- |
|
25 |
2.0 |
2.5 |
3.0 |
2.5 |
3.4 |
4.5 |
- |
- |
- |
- |
|
35 |
2.0 |
2.5 |
3.0 |
2.5 |
3.4 |
4.5 |
5.5 |
- |
- |
- |
|
50 – 185 |
2.0 |
2.5 |
3.0 |
2.5 |
3.4 |
4.5 |
5.5 |
8.0 |
9.3 |
10.5 |
|
240 |
2.0 |
2.6 |
3.0 |
2.6 |
3.4 |
4.5 |
5.5 |
8.0 |
9.3 |
10.5 |
|
300 |
2.0 |
2.8 |
3.0 |
2.8 |
3.4 |
4.5 |
5.5 |
8.0 |
9.3 |
10.5 |
|
400 |
2.0 |
3.0 |
3.0 |
3.0 |
3.4 |
4.5 |
5.5 |
8.0 |
9.3 |
10.5 |
|
500 - 1600 |
2.2-2.8 |
3.2 |
3.2 |
3.2 |
3.4 |
4.5 |
5.5 |
8.0 |
9.3 |
10.5 |
*PVX izolyatsiyasining qalinligi 3,6/6KV kabellar uchun 3,4 mm (1- 1600 mm sq) ni tashkil qiladi.
|
Izolyatsiyaiekranda |
Izolyatsiya ekrani izolyatsiya ustiga siqib chiqarilgan metall bo'lmagan, yarim o'tkazuvchan birikmaning ekstrude qilingan qatlamidan iborat. Ekstrudirovka qilingan yarim o'tkazgich qatlami birlashma yoki tugatish uchun olib tashlanishi mumkin bo'lgan bog'langan yoki sovuq tozalanadigan yarim o'tkazgich birikmasidan iborat bo'lishi kerak. Variant sifatida, metall qatlam uchun to'shak sifatida ekstrudirovka qilingan yarim o'tkazgich qatlami ustida yarim o'tkazgichli lenta qo'llanilishi mumkin. Minimal qalinligi 0,3 mm va maksimal qarshilik 90 gradusda 500 Ohm-m. Ekran barcha havo bo'shliqlarini istisno qilish uchun izolyatsiyaga mahkam o'rnatiladi va uni saytda osongina qo'l bilan olib tashlash mumkin. Izolyatsiya ekrani ham PVX, ham EPR/HEPR izolyatsiyali 1,8/3KV va 3,6/6KV kabellar uchun kerak emas. Uzunlamasına suv o'tkazmasligini ta'minlash uchun ekran yarim o'tkazgichli suvni to'sib qo'yadigan shishadi lenta bilan qoplangan bo'lishi mumkin. |
|
Metall qatlam |
Metall qatlam alohida yadrolarga yoki yadro majmuasiga birgalikda qo'llanilishi mumkin. |
Quyidagi turdagi metall qatlamlar taqdim etiladi:
1) Metall ekran
2) Konsentrik Supero'tkazuvchilar
3) Metall qoplama
4) Metall zirh
Metall ekran mis lentalardan yoki mis simlarning konsentrik qatlamidan yoki tuproqli oqim yo'lini ta'minlash uchun lentalar va simlar birikmasidan iborat bo'lishi kerak. Konsentrik o'tkazgich to'g'ridan-to'g'ri izolyatsiyaga yoki izolyatsiya ekraniga yoki ichki qoplamaga qo'llaniladi. Metall qobiq mahkam o'rnatiladigan choksiz quvur sifatida qo'llaniladigan qo'rg'oshin yoki qo'rg'oshin qotishmasidan iborat. Metall zirh tekis simli zirh, dumaloq simli zirh va ikki tarmoqli zirhdan iborat.
Jadval 2. Metall ekranning minimal umumiy ko'ndalang kesimi
|
Nom. Kabelning ko'ndalang kesimi maydoni |
Min. Metall ekranning ko'ndalang kesimi |
Mis simli ekranning DC qarshiligi |
|
mm% 5e2 |
mm% 5e2 |
mm |
|
120 gacha |
16 |
1.06 |
|
150-300 |
25 |
0.72 |
|
400-630 |
35 |
0.51 |
|
800-1000 |
50 |
0.35 |
|
Ajratish qobig'i (zirhli kabel uchun) |
Ajratish qobig'i zirh ostida qo'llaniladigan ekstrudirovka qilingan PVX, PE yoki LSZH qatlamini o'z ichiga oladi. Nominal qalinlik {0}}.02Du + 0.6mm boʻyicha hisoblanadi, bunda Du — gʻilof ostidagi xayoliy diametri mm. Qo'rg'oshin qobig'i bo'lmagan kabellar uchun ajratuvchi qobiqning nominal qalinligi 1,2 mm dan kam bo'lmasligi kerak. Ajratish qobig'i qo'rg'oshin niqobi ostida qo'llaniladigan kabellar uchun ajratuvchi qobiqning nominal qalinligi 1,0 mm dan kam bo'lmasligi kerak. |
|
Yopilgan choyshablar (zirhli qo'rg'oshin qoplamali kabel uchun) |
Yopilgan choyshablar singdirilgan / sintetik aralash qog'oz lentalaridan yoki ushbu qog'oz lentalarning ikki qatlamidan so'ng bir necha qatlamli ajoyib materiallardan iborat. Qalinligi taxminan 1,5 mm. |
|
Qurol (zirhli kabel uchun) |
Zirh extruded ajratish niqobi ostida spiral shaklida qo'llaniladigan dumaloq alyuminiy simli zirhdan iborat. |
Jadval 3. Dumaloq zirh simining diametri
|
Zirh ostidagi xayoliy diametr |
Zirh simining diametri |
|
|
mm |
mm |
|
|
> |
< |
|
|
- |
10 |
0.8 |
|
10 |
15 |
1.25 |
|
15 |
25 |
1.6 |
|
25 |
35 |
2.0 |
|
35 |
60 |
2.5 |
|
60 |
- |
3.15 |
|
Shift ustida |
Umumiy qobiq ekstrudirovka qilingan termoplastik birikma (opsiya sifatida PVX, pe yoki LSZH taklif qilinishi mumkin.) yoki elastomerik birikma (poliklorpren CSP yoki xlorosulfonatlangan pe) qatlamidan iborat. G'ilofning nominal qalinligi 0.035D+1 bo'yicha hisoblanadi, bunda D - mm dagi to'g'ridan-to'g'ri qoplama ostidagi xayoliy diametri. Zirhli bo'lmagan kabellar va zirh, metall ekran yoki konsentrik o'tkazgich ustiga qo'llanilmagan ustki qoplamali kabellar uchun g'ilofning nominal qalinligi 1,4 mm dan kam bo'lmasligi kerak. Va zirh, metall ekran yoki konsentrik o'tkazgich ustiga qo'yilgan qoplamali kabellar uchun g'ilofning nominal qalinligi 1,8 mm dan kam bo'lmasligi kerak. |
Jismoniy xossalari
|
Ishlash harorati |
70 darajagacha (PVX izolyatsiyasi); 90 darajagacha (XLPE yoki EPR izolyatsiyasi) |
|
Harorat diapazoni |
-5 daraja (PVX yoki LSZH niqobi ostida); -20 daraja (PE niqobi ostida) |
|
Qisqa tutashuv harorati (maksimal 5 soniya) |
140-160 daraja (PVX izolyatsiyasi); 250 daraja (XLPE yoki EPR izolyatsiyasi) |
|
Bükme radiusi |
12 x OD |
Jadval 4. Nominal / Ishlash / Sinov kuchlanishlari
|
Nominal kuchlanish Uo/U |
Ishlash kuchlanishi (Um) |
Sinov kuchlanishi (rms) |
|
1,8/3KV |
3,6 kV |
6,5 kV |
|
3,6/6KV |
7,2 KV |
12,5 kV |
|
6/10KV |
12KV |
21KV |
|
8,7/15KV |
17,5 kV |
30,5 kV |
|
12/20KV |
24KV |
42 kV |
|
18/30KV |
36 kV |
63 kV |
|
21/35KV |
42 kV |
73,5(53)*KV |
|
26/35KV |
42 kV |
91(65)*KV |
*21/35KV va 26/35KV quvvat chastotali kuchlanish sinovi quyidagi sharoitlarda amalga oshirilishi mumkin: 2,5Uo x 30min yoki 3,0Uo x 15mins.
Qavs ichidagi raqamlar 3.0Uo x 1,5 daqiqalik sinov qiymatlariga ishora qiladi.
4.Bir yadroli 1.8/3KV (Um=3.6KV) oʻlchovli maʼlumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
CU |
Al |
Kun.k. |
Al |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
10 |
2.0 |
0.1 |
16 |
1.8 |
13 |
240 |
180 |
1.2 |
1.6 |
1.8 |
18 |
460 |
400 |
|
16 |
2.0 |
0.1 |
16 |
1.8 |
13 |
300 |
200 |
1.2 |
1.6 |
1.8 |
19 |
530 |
430 |
|
25 |
2.0 |
0.1 |
16 |
1.8 |
15 |
410 |
250 |
1.2 |
1.6 |
1.8 |
20 |
650 |
500 |
|
35 |
2.0 |
0.1 |
16 |
1.8 |
16 |
510 |
300 |
1.2 |
1.6 |
1.8 |
21 |
780 |
560 |
|
50 |
2.0 |
0.1 |
16 |
1.8 |
17 |
640 |
350 |
1.2 |
1.6 |
1.8 |
22 |
930 |
640 |
|
70 |
2.0 |
0.1 |
16 |
1.8 |
19 |
850 |
440 |
1.2 |
1.6 |
1.8 |
24 |
1170 |
750 |
|
95 |
2.0 |
0.1 |
16 |
1.8 |
20 |
1130 |
540 |
1.2 |
1.6 |
1.8 |
26 |
1460 |
870 |
|
120 |
2.0 |
0.1 |
16 |
1.8 |
22 |
1370 |
630 |
1.2 |
1.6 |
1.8 |
27 |
1730 |
990 |
|
150 |
2.0 |
0.1 |
25 |
1.8 |
23 |
1650 |
730 |
1.2 |
1.6 |
1.8 |
29 |
2030 |
1110 |
|
185 |
2.0 |
0.1 |
25 |
1.8 |
25 |
2010 |
860 |
1.2 |
1.6 |
1.9 |
30 |
2430 |
1280 |
|
240 |
2.0 |
0.1 |
25 |
1.8 |
27 |
2570 |
1050 |
1.2 |
1.6 |
2.0 |
33 |
3040 |
1530 |
|
300 |
2.0 |
0.1 |
25 |
1.8 |
29 |
3160 |
1250 |
1.2 |
2.0 |
2.1 |
36 |
3760 |
1860 |
|
400 |
2.0 |
0.1 |
35 |
1.9 |
33 |
3980 |
1560 |
1.2 |
2.0 |
2.2 |
39 |
4660 |
2230 |
|
500 |
2.2 |
0.1 |
35 |
2.1 |
35.5 |
4910 |
1905 |
1.3 |
2.5 |
2.5 |
43 |
5930 |
2930 |
|
630 |
2.4 |
0.1 |
35 |
2.2 |
39.7 |
6340 |
2420 |
1.4 |
2.5 |
2.6 |
49 |
7370 |
3430 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
KA |
KA |
μΩ/m |
nH/m |
μΩ/ m |
μΩ/ m |
||||
|
10 |
1830/3080 |
2330/3920 |
1.4/0.9 |
182 |
0.27 |
2.6 |
0.2 |
151 |
201 |
384 |
558 |
2332 |
3846 |
2332 |
3840 |
|
16 |
1150/1910 |
1460/2420 |
2.2/1.4 |
201 |
0.29 |
2.6 |
0.3 |
140 |
193 |
362 |
546 |
1462 |
2411 |
1478 |
2420 |
|
25 |
727/1200 |
927/1538 |
3.6/2.3 |
222 |
0.32 |
2.6 |
0.3 |
131 |
185 |
345 |
535 |
936 |
1544 |
952 |
1554 |
|
35 |
524/868 |
668/1113 |
5.0/3.2 |
251 |
0.35 |
2.6 |
0.4 |
122 |
178 |
327 |
524 |
679 |
1121 |
695 |
1131 |
|
50 |
387/641 |
494/822 |
6.8/4.4 |
281 |
0.39 |
2.6 |
0.4 |
116 |
172 |
313 |
514 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
341 |
0.45 |
2.6 |
0.5 |
110 |
165 |
300 |
495 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
397 |
0.50 |
2.6 |
0.5 |
104 |
160 |
287 |
485 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
430 |
0.55 |
2.6 |
0.6 |
104 |
159 |
283 |
480 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/266 |
21.2/13.5 |
464 |
0.59 |
4.3 |
0.6 |
100 |
156 |
280 |
475 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
513 |
0.65 |
4.3 |
0.7 |
98 |
154 |
274 |
465 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
573 |
0.70 |
4.3 |
0.9 |
94 |
150 |
267 |
459 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
652 |
0.72 |
4.3 |
1.0 |
91 |
147 |
260 |
455 |
128 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
727 |
0.75 |
5.8 |
1.1 |
90 |
147 |
253 |
445 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81 |
72.3/46.2 |
754 |
0.79 |
5.8 |
1.2 |
89 |
145 |
248 |
435 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64 |
91.2/58.3 |
786 |
0.87 |
5.8 |
1.3 |
86 |
143 |
245 |
425 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
846 |
0.91 |
8.2 |
1.4 |
85 |
142 |
243 |
415 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
916 |
0.99 |
8.2 |
1.5 |
83 |
141 |
239 |
405 |
88 |
95 |
144 |
148 |
Bir yadroli 3,6/6KV (Um=7,2KV)
O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
10 |
2.5 |
0.1 |
16 |
1.8 |
16 |
320 |
260 |
1.2 |
1.6 |
1.8 |
22 |
610 |
550 |
|
16 |
2.5 |
0.1 |
16 |
1.8 |
16 |
390 |
290 |
1.2 |
1.6 |
1.8 |
22 |
680 |
580 |
|
25 |
2.5 |
0.1 |
16 |
1.8 |
18 |
500 |
340 |
1.2 |
1.6 |
1.8 |
23 |
810 |
660 |
|
35 |
2.5 |
0.1 |
16 |
1.8 |
19 |
610 |
400 |
1.2 |
1.6 |
1.8 |
24 |
940 |
730 |
|
50 |
2.5 |
0.1 |
16 |
1.8 |
20 |
750 |
450 |
1.2 |
1.6 |
1.8 |
26 |
1100 |
810 |
|
70 |
2.5 |
0.1 |
16 |
1.8 |
22 |
970 |
550 |
1.2 |
1.6 |
1.8 |
27 |
1350 |
930 |
|
95 |
2.5 |
0.1 |
16 |
1.8 |
23 |
1250 |
660 |
1.2 |
1.6 |
1.9 |
29 |
1670 |
1080 |
|
120 |
2.5 |
0.1 |
16 |
1.8 |
25 |
1500 |
760 |
1.2 |
1.6 |
1.9 |
31 |
1950 |
1200 |
|
150 |
2.5 |
0.1 |
25 |
1.8 |
26 |
1790 |
860 |
1.2 |
1.6 |
2.0 |
32 |
2270 |
1350 |
|
185 |
2.5 |
0.1 |
25 |
1.8 |
28 |
2150 |
1000 |
1.2 |
2.0 |
2.1 |
35 |
2770 |
1620 |
|
240 |
2.6 |
0.1 |
25 |
1.9 |
31 |
2770 |
1250 |
1.2 |
2.0 |
2.2 |
38 |
3440 |
1930 |
|
300 |
2.8 |
0.1 |
25 |
2.0 |
34 |
3400 |
1500 |
1.2 |
2.0 |
2.2 |
41 |
4120 |
2210 |
|
400 |
3.0 |
0.1 |
35 |
2.1 |
38 |
4280 |
1850 |
1.3 |
2.5 |
2.4 |
46 |
5250 |
2820 |
|
500 |
3.2 |
0.1 |
35 |
2.1 |
41.5 |
5325 |
2240 |
1.4 |
2.5 |
2.6 |
50 |
6520 |
3520 |
|
630 |
3.2 |
0.1 |
35 |
2.2 |
45.3 |
6745 |
2750 |
1.5 |
2.5 |
2.7 |
56 |
7960 |
4020 |
|
800 |
3.2 |
0.1 |
50 |
2.4 |
49.9 |
8290 |
3310 |
1.5 |
2.5 |
2.8 |
59 |
9660 |
4820 |
|
1000 |
3.2 |
0.1 |
50 |
2.5 |
54.2 |
10255 |
3990 |
1.6 |
2.5 |
3.0 |
63 |
11690 |
5540 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
KA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
10 |
1830/3080 |
2330/3920 |
1.4/0.9 |
202 |
0.26 |
2.6 |
0.4 |
160 |
214 |
420 |
610 |
2332 |
3846 |
2345 |
3840 |
|
16 |
1150/1910 |
1460/2420 |
2.2/1.4 |
232 |
0.29 |
2.6 |
0.4 |
152 |
205 |
410 |
600 |
1462 |
2411 |
1478 |
2421 |
|
25 |
727/1200 |
927/1538 |
3.6/2.3 |
262 |
0.32 |
2.6 |
0.4 |
142 |
196 |
400 |
590 |
936 |
1544 |
952 |
1554 |
|
35 |
524/868 |
668/1113 |
5.0/3.2 |
291 |
0.35 |
2.6 |
0.5 |
133 |
187 |
390 |
580 |
679 |
1121 |
695 |
1131 |
|
50 |
387/641 |
494/822 |
6.8/4.4 |
321 |
0.39 |
2.6 |
0.5 |
121 |
179 |
380 |
570 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
371 |
0.45 |
2.6 |
0.6 |
115 |
173 |
370 |
550 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
417 |
0.50 |
2.6 |
0.6 |
110 |
168 |
350 |
540 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
459 |
0.55 |
2.6 |
0.7 |
107 |
165 |
340 |
520 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
494 |
0.59 |
4.3 |
0.7 |
103 |
161 |
330 |
510 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
543 |
0.65 |
4.3 |
0.8 |
100 |
158 |
320 |
500 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
583 |
0.70 |
4.3 |
0.9 |
97 |
155 |
310 |
490 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
602 |
0.72 |
4.3 |
1.0 |
95 |
153 |
300 |
490 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
627 |
0.75 |
5.8 |
1.1 |
92 |
150 |
290 |
480 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81 |
72.3/46.2 |
654 |
0.79 |
5.8 |
1.2 |
90 |
147 |
290 |
470 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64 |
91.2/58.3 |
726 |
0.87 |
5.8 |
1.3 |
87 |
145 |
280 |
460 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
786 |
0.91 |
8.2 |
1.4 |
85 |
143 |
270 |
460 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
856 |
0.99 |
8.2 |
1.5 |
83 |
141 |
260 |
450 |
88 |
95 |
144 |
148 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 6/10KV (Um{2}}KV)
O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
Al |
Kun.k. |
AL |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
16 |
3.4 |
0.1 |
16 |
1.8 |
18 |
450 |
350 |
1.2 |
1.6 |
1.8 |
24 |
770 |
670 |
|
25 |
3.4 |
0.1 |
16 |
1.8 |
20 |
560 |
400 |
1.2 |
1.6 |
1.8 |
25 |
910 |
750 |
|
35 |
3.4 |
0.1 |
16 |
1.8 |
21 |
680 |
460 |
1.2 |
1.6 |
1.8 |
26 |
1040 |
820 |
|
50 |
3.4 |
0.1 |
16 |
1.8 |
22 |
810 |
520 |
1.2 |
1.6 |
1.8 |
28 |
1190 |
900 |
|
70 |
3.4 |
0.1 |
16 |
1.8 |
24 |
1050 |
620 |
1.2 |
1.6 |
1.9 |
29 |
1470 |
1040 |
|
95 |
3.4 |
0.1 |
16 |
1.8 |
25 |
1320 |
730 |
1.2 |
1.6 |
2.0 |
31 |
1780 |
1190 |
|
120 |
3.4 |
0.1 |
16 |
1.8 |
27 |
1580 |
840 |
1.2 |
2.0 |
2.0 |
34 |
2150 |
1410 |
|
150 |
3.4 |
0.1 |
25 |
1.9 |
28 |
1880 |
960 |
1.2 |
2.0 |
2.1 |
35 |
2480 |
1560 |
|
185 |
3.4 |
0.1 |
25 |
1.9 |
30 |
2250 |
1100 |
1.2 |
2.0 |
2.1 |
37 |
2890 |
1730 |
|
240 |
3.4 |
0.1 |
25 |
2.0 |
33 |
2870 |
1350 |
1.2 |
2.0 |
2.2 |
40 |
3570 |
2050 |
|
300 |
3.4 |
0.1 |
25 |
2.1 |
35 |
3490 |
1580 |
1.2 |
2.0 |
2.3 |
42 |
4230 |
2330 |
|
400 |
3.4 |
0.1 |
35 |
2.2 |
39 |
4350 |
1920 |
1.3 |
2.5 |
2.4 |
47 |
5320 |
2890 |
|
500 |
3.4 |
0.1 |
35 |
2.2 |
39.9 |
5235 |
2240 |
1.4 |
2.5 |
2.5 |
51 |
6510 |
3530 |
|
630 |
3.4 |
0.1 |
35 |
2.3 |
43.7 |
6675 |
2765 |
1.5 |
2.5 |
2.6 |
56 |
7960 |
4050 |
|
800 |
3.4 |
0.1 |
50 |
2.5 |
48.6 |
8225 |
3330 |
1.5 |
2.5 |
2.7 |
59 |
9670 |
4850 |
|
1000 |
3.4 |
0.1 |
50 |
2.6 |
52.9 |
10210 |
4030 |
1.6 |
2.5 |
2.9 |
63 |
11710 |
5570 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
AL |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
kA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
16 |
1150/1910 |
1460/2420 |
2.2/1.4 |
187 |
0.39 |
2.6 |
0.5 |
152 |
216 |
480 |
680 |
1462 |
2411 |
1478 |
2421 |
|
25 |
727/1200 |
927/1538 |
3.6/2.3 |
208 |
0.42 |
2.6 |
0.5 |
144 |
210 |
460 |
660 |
936 |
1544 |
952 |
1554 |
|
35 |
524/868 |
668/1113 |
5.0/3.2 |
229 |
0.46 |
2.6 |
0.6 |
136 |
200 |
440 |
640 |
679 |
1121 |
695 |
1131 |
|
50 |
387/641 |
494/822 |
6.8/4.4 |
252 |
0.50 |
2.6 |
0.6 |
131 |
195 |
420 |
620 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
288 |
0.58 |
2.6 |
0.7 |
122 |
188 |
390 |
600 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
323 |
0.65 |
2.6 |
0.7 |
122 |
182 |
390 |
580 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
353 |
0.71 |
2.6 |
0.8 |
116 |
172 |
370 |
550 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
380 |
0.76 |
4.3 |
0.8 |
110 |
166 |
350 |
530 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
416 |
0.83 |
4.3 |
0.9 |
107 |
166 |
340 |
530 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
460 |
0.92 |
4.3 |
0.9 |
104 |
163 |
330 |
520 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
506 |
1.01 |
4.3 |
1.0 |
100 |
157 |
320 |
500 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
561 |
1.12 |
5.8 |
1.1 |
94 |
154 |
300 |
490 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81.0 |
72.3/46.2 |
619 |
1.24 |
5.8 |
1.2 |
91 |
151 |
290 |
480 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64.0 |
91.2/58.3 |
698 |
1.37 |
5.8 |
1.3 |
91 |
148 |
290 |
470 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
780 |
1.39 |
8.2 |
1.4 |
88 |
144 |
280 |
470 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
860 |
1.54 |
8.2 |
1.5 |
85 |
143 |
270 |
460 |
88 |
95 |
144 |
148 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 8,7/15KV (Um=17,5KV)O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
Al |
CU |
Al |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
25 |
4.5 |
0.1 |
16 |
1.8 |
22 |
640 |
480 |
1.2 |
1.6 |
1.8 |
28 |
1020 |
860 |
|
35 |
4.5 |
0.1 |
16 |
1.8 |
23 |
760 |
540 |
1.2 |
1.6 |
1.9 |
29 |
1170 |
950 |
|
50 |
4.5 |
0.1 |
16 |
1.8 |
24 |
900 |
610 |
1.2 |
1.6 |
1.9 |
30 |
1340 |
1040 |
|
70 |
4.5 |
0.1 |
16 |
1.8 |
26 |
1140 |
710 |
1.2 |
1.6 |
2.0 |
32 |
1610 |
1190 |
|
95 |
4.5 |
0.1 |
16 |
1.8 |
27 |
1420 |
830 |
1.2 |
2.0 |
2.1 |
35 |
2020 |
1430 |
|
120 |
4.5 |
0.1 |
16 |
1.9 |
29 |
1700 |
950 |
1.2 |
2.0 |
2.1 |
36 |
2310 |
1570 |
|
150 |
4.5 |
0.1 |
25 |
1.9 |
31 |
1990 |
1070 |
1.2 |
2.0 |
2.2 |
38 |
2660 |
1740 |
|
185 |
4.5 |
0.1 |
25 |
2.0 |
32 |
2380 |
1230 |
1.2 |
2.0 |
2.2 |
39 |
3070 |
1920 |
|
240 |
4.5 |
0.1 |
25 |
2.1 |
35 |
3010 |
1490 |
1.2 |
2.0 |
2.3 |
42 |
3750 |
2240 |
|
300 |
4.5 |
0.1 |
25 |
2.1 |
37 |
3620 |
1720 |
1.3 |
2.5 |
2.4 |
46 |
4590 |
2690 |
|
400 |
4.5 |
0.1 |
35 |
2.2 |
41 |
4490 |
2070 |
1.3 |
2.5 |
2.5 |
49 |
5550 |
3120 |
|
500 |
4.5 |
0.1 |
35 |
2.3 |
43 |
5460 |
2460 |
1.3 |
2.5 |
2.6 |
52 |
6590 |
3600 |
|
630 |
4.5 |
0.1 |
35 |
2.4 |
48 |
6790 |
2590 |
1.4 |
2.5 |
2.7 |
57 |
8060 |
4110 |
|
800 |
4.5 |
0.1 |
50 |
2.6 |
52 |
8420 |
3570 |
1.5 |
2.5 |
2.8 |
61 |
9800 |
4970 |
|
1000 |
4.5 |
0.1 |
50 |
2.7 |
55 |
10330 |
4180 |
1.6 |
2.5 |
3.0 |
65 |
10850 |
5710 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
kA |
pF% 2fm |
mA% 2fm |
kA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
25 |
727/1200 |
927/1538 |
3.6/2.3 |
171 |
0.47 |
2.6 |
0.6 |
150 |
210 |
480 |
680 |
936 |
1544 |
952 |
1554 |
|
35 |
524/868 |
668/1113 |
5.0/3.2 |
187 |
0.51 |
2.6 |
0.6 |
141 |
207 |
460 |
660 |
679 |
1121 |
695 |
1131 |
|
50 |
387/641 |
494/822 |
6.8/4.4 |
204 |
0.57 |
2.6 |
0.7 |
138 |
195 |
440 |
640 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
232 |
0.63 |
2.6 |
0.7 |
132 |
188 |
420 |
600 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
258 |
0.71 |
2.6 |
0.8 |
126 |
182 |
400 |
580 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
281 |
0.74 |
2.6 |
0.8 |
119 |
179 |
380 |
570 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
301 |
0.79 |
4.3 |
0.9 |
113 |
176 |
360 |
560 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
329 |
0.87 |
4.3 |
0.9 |
110 |
170 |
350 |
540 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
363 |
0.96 |
4.3 |
1.0 |
107 |
166 |
340 |
530 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
398 |
1.03 |
4.3 |
1.1 |
104 |
160 |
330 |
510 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
439 |
1.17 |
5.8 |
1.2 |
97 |
157 |
310 |
500 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81 |
72.3/46.2 |
483 |
1.28 |
5.8 |
1.3 |
94 |
154 |
300 |
490 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64 |
91.2/58.3 |
534 |
1.42 |
5.8 |
1.4 |
91 |
151 |
290 |
480 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
590 |
1.61 |
8.2 |
1.4 |
91 |
147 |
290 |
470 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
640 |
1.75 |
8.2 |
1.5 |
88 |
144 |
280 |
460 |
88 |
95 |
144 |
148 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 12/20KV (Um{2}}KV)
O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
AL |
Kun.k. |
Al |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
25 |
5.5 |
0.1 |
16 |
1.8 |
24 |
720 |
560 |
1.2 |
1.6 |
1.8 |
29 |
1200 |
980 |
|
35 |
5.5 |
0.1 |
16 |
1.8 |
25 |
840 |
620 |
1.2 |
1.6 |
1.9 |
30 |
1350 |
1070 |
|
50 |
5.5 |
0.1 |
16 |
1.8 |
26 |
990 |
690 |
1.2 |
2.0 |
2.0 |
33 |
1550 |
1250 |
|
70 |
5.5 |
0.1 |
16 |
1.8 |
28 |
1230 |
800 |
1.2 |
2.0 |
2.1 |
35 |
1840 |
1420 |
|
95 |
5.5 |
0.1 |
16 |
1.9 |
30 |
1530 |
940 |
1.2 |
2.0 |
2.1 |
37 |
2160 |
1570 |
|
120 |
5.5 |
0.1 |
16 |
2.0 |
31 |
1810 |
1050 |
1.2 |
2.0 |
2.2 |
38 |
2470 |
1730 |
|
150 |
5.5 |
0.1 |
25 |
2.0 |
33 |
2110 |
1190 |
1.2 |
2.0 |
2.2 |
40 |
2810 |
1890 |
|
185 |
5.5 |
0.1 |
25 |
2.1 |
35 |
2510 |
1360 |
1.2 |
2.0 |
2.3 |
42 |
3240 |
2090 |
|
240 |
5.5 |
0.1 |
25 |
2.1 |
38 |
3130 |
1610 |
1.3 |
2.5 |
2.4 |
45 |
4150 |
2580 |
|
300 |
5.5 |
0.1 |
25 |
2.2 |
40 |
3760 |
1860 |
1.3 |
2.5 |
2.5 |
48 |
4800 |
2890 |
|
400 |
5.5 |
0.1 |
35 |
2.3 |
43 |
4650 |
2220 |
1.4 |
2.5 |
2.6 |
52 |
5780 |
3350 |
|
500 |
5.5 |
0.1 |
35 |
2.4 |
46 |
5530 |
2545 |
1.5 |
2.5 |
2.7 |
55 |
6850 |
3850 |
|
630 |
5.5 |
0.1 |
35 |
2.5 |
50 |
6700 |
3100 |
1.5 |
2.5 |
2.9 |
60 |
8380 |
4400 |
|
800 |
5.5 |
0.1 |
50 |
2.6 |
55 |
8580 |
3690 |
1.6 |
2.5 |
3.0 |
64 |
10130 |
5270 |
|
1000 |
5.5 |
0.1 |
50 |
2.7 |
59 |
10620 |
4445 |
1.7 |
2.5 |
3.1 |
68 |
12180 |
6000 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
KA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
25 |
727/1200 |
927/1538 |
3.6/2.3 |
142 |
0.62 |
2.6 |
0.6 |
162 |
214 |
490 |
680 |
936 |
1544 |
952 |
1554 |
|
35 |
524/868 |
668/1113 |
5.0/3.2 |
162 |
0.65 |
2.6 |
0.7 |
150 |
207 |
470 |
660 |
679 |
1121 |
695 |
1131 |
|
50 |
387/641 |
494/822 |
6.8/4.4 |
177 |
0.71 |
2.6 |
0.8 |
141 |
201 |
450 |
640 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
200 |
0.80 |
2.6 |
0.8 |
135 |
195 |
430 |
620 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
222 |
0.89 |
2.6 |
0.9 |
129 |
188 |
410 |
600 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
241 |
0.96 |
2.6 |
0.9 |
122 |
182 |
390 |
580 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
257 |
1.03 |
4.3 |
1.0 |
116 |
176 |
370 |
560 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
280 |
1.12 |
4.3 |
1.0 |
116 |
173 |
370 |
550 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
307 |
1.23 |
4.3 |
1.1 |
110 |
170 |
350 |
540 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
336 |
1.34 |
4.3 |
1.2 |
107 |
166 |
340 |
530 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
370 |
1.48 |
5.8 |
1.3 |
100 |
160 |
320 |
510 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81 |
72.3/46.2 |
406 |
1.62 |
5.8 |
1.4 |
97 |
154 |
310 |
490 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64 |
91.2/58.3 |
449 |
1.80 |
5.8 |
1.5 |
94 |
151 |
300 |
480 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
490 |
1.85 |
8.2 |
1.6 |
91 |
151 |
290 |
480 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
540 |
2.03 |
8.2 |
1.7 |
87 |
148 |
280 |
470 |
88 |
95 |
144 |
148 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 18/30KV (Um{2}}KV)O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
AL |
Kun.k. |
Al |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
50 |
8.0 |
0.1 |
16 |
2.0 |
31 |
1250 |
960 |
1.2 |
2.0 |
2.2 |
38 |
1910 |
1640 |
|
70 |
8.0 |
0.1 |
16 |
2.0 |
34 |
1510 |
1090 |
1.2 |
2.0 |
2.3 |
41 |
2240 |
1820 |
|
95 |
8.0 |
0.1 |
16 |
2.1 |
35 |
1830 |
1240 |
1.2 |
2.0 |
2.3 |
42 |
2570 |
1980 |
|
120 |
8.0 |
0.1 |
16 |
2.1 |
37 |
2110 |
1360 |
1.3 |
2.5 |
2.4 |
45 |
3060 |
2310 |
|
150 |
8.0 |
0.1 |
25 |
2.2 |
38 |
2420 |
1510 |
1.3 |
2.5 |
2.5 |
47 |
3430 |
2510 |
|
185 |
8.0 |
0.1 |
25 |
2.2 |
40 |
2830 |
1680 |
1.3 |
2.5 |
2.5 |
50 |
3890 |
2720 |
|
240 |
8.0 |
0.1 |
25 |
2.3 |
43 |
3500 |
1980 |
1.4 |
2.5 |
2.6 |
52 |
4630 |
3120 |
|
300 |
8.0 |
0.1 |
25 |
2.4 |
45 |
4150 |
2250 |
1.4 |
2.5 |
2.7 |
54 |
5330 |
3430 |
|
400 |
8.0 |
0.1 |
35 |
2.5 |
49 |
5070 |
2640 |
1.5 |
2.5 |
2.8 |
58 |
6360 |
3930 |
|
500 |
8.0 |
0.1 |
35 |
2.6 |
52 |
5945 |
2965 |
1.6 |
2.5 |
2.9 |
61 |
7670 |
4490 |
|
630 |
8.0 |
0.1 |
35 |
2.7 |
56 |
7445 |
3555 |
1.7 |
2.5 |
3.0 |
65 |
8870 |
5020 |
|
800 |
8.0 |
0.1 |
50 |
2.8 |
61 |
9060 |
4180 |
1.9 |
2.5 |
3.2 |
69 |
10790 |
5980 |
|
1000 |
8.0 |
0.1 |
50 |
2.9 |
65 |
11140 |
4980 |
2.0 |
2.5 |
3.3 |
73 |
12860 |
6730 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
AL |
Kun.k. |
Al |
||||||||||||
|
mm^2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
kA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
50 |
387/641 |
494/822 |
6.8/4.4 |
138 |
0.83 |
2.6 |
1.0 |
151 |
214 |
480 |
680 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
154 |
0.92 |
2.6 |
1.0 |
144 |
201 |
460 |
640 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
169 |
1.01 |
2.6 |
1.1 |
138 |
195 |
440 |
620 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
183 |
1.10 |
2.6 |
1.1 |
132 |
188 |
420 |
600 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
194 |
1.16 |
4.3 |
1.2 |
126 |
182 |
400 |
580 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
210 |
1.26 |
4.3 |
1.2 |
122 |
182 |
390 |
580 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
229 |
1.37 |
4.3 |
1.3 |
119 |
176 |
380 |
560 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
249 |
1.49 |
4.3 |
1.4 |
113 |
173 |
360 |
550 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
273 |
1.64 |
5.8 |
1.5 |
107 |
163 |
340 |
520 |
113 |
141 |
164 |
184 |
|
500 |
36.6/60.5 |
51/81 |
72.3/46.2 |
298 |
1.79 |
5.8 |
1.6 |
104 |
163 |
330 |
520 |
105 |
124 |
158 |
171 |
|
630 |
28.3/46.9 |
42/64 |
91.2/58.3 |
327 |
1.96 |
5.8 |
1.7 |
100 |
160 |
320 |
510 |
97 |
110 |
151 |
160 |
|
800 |
22.1/36.7 |
35/55 |
114.4/75.0 |
350 |
1.98 |
8.2 |
1.8 |
97 |
154 |
310 |
490 |
92 |
101 |
147 |
153 |
|
1000 |
17.6/29.1 |
30/46 |
143.0/94.0 |
380 |
2.15 |
8.2 |
1.9 |
94 |
149 |
300 |
490 |
88 |
95 |
144 |
148 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Yagona yadroli 21/35KV (Um{2}}KV) nsional maʼlumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||
|
mm^2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
50 |
9.3 |
0.1 |
16 |
2.0 |
35.7 |
1526 |
1239 |
1.2 |
2.0 |
2.3 |
43.5 |
2331 |
2116 |
|
70 |
9.3 |
0.1 |
16 |
2.1 |
37.6 |
1809 |
1393 |
1.2 |
2.5 |
2.4 |
46.6 |
2680 |
2325 |
|
95 |
9.3 |
0.1 |
16 |
2.2 |
39.4 |
2123 |
1555 |
1.2 |
2.5 |
2.5 |
48.4 |
2981 |
2482 |
|
120 |
9.3 |
0.1 |
16 |
2.2 |
40.8 |
2405 |
1688 |
1.4 |
2.5 |
2.5 |
49.8 |
3487 |
2867 |
|
150 |
9.3 |
0.1 |
25 |
2.2 |
42.3 |
2733 |
1838 |
1.4 |
2.5 |
2.6 |
51.5 |
3870 |
3055 |
|
185 |
9.3 |
0.1 |
25 |
2.3 |
44.7 |
3216 |
2082 |
1.4 |
2.5 |
2.6 |
53.5 |
4420 |
3370 |
|
240 |
9.3 |
0.1 |
25 |
2.4 |
46.9 |
3766 |
2333 |
1.4 |
2.5 |
2.7 |
55.8 |
4981 |
3676 |
|
300 |
9.3 |
0.1 |
25 |
2.4 |
49.3 |
4408 |
2605 |
1.4 |
2.5 |
2.8 |
58.5 |
5661 |
3971 |
|
400 |
9.3 |
0.1 |
35 |
2.5 |
52.3 |
5473 |
3057 |
1.6 |
2.5 |
2.9 |
61.7 |
6865 |
4550 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA/m |
KA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
50 |
387/641 |
494/822 |
6.8/4.4 |
130 |
0.89 |
2.6 |
1.1 |
156 |
220 |
495 |
700 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
144 |
0.98 |
2.6 |
1.1 |
150 |
204 |
475 |
650 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
159 |
1.06 |
2.6 |
1.2 |
142 |
198 |
455 |
630 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
171 |
1.18 |
2.6 |
1.2 |
137 |
191 |
435 |
610 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
180 |
1.26 |
4.3 |
1.3 |
131 |
185 |
415 |
590 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
193 |
1.34 |
4.3 |
1.3 |
125 |
185 |
400 |
590 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
210 |
1.45 |
4.3 |
1.4 |
123 |
179 |
390 |
570 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
228 |
1.57 |
4.3 |
1.5 |
116 |
176 |
370 |
560 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
249 |
1.74 |
5.8 |
1.6 |
110 |
166 |
350 |
530 |
113 |
141 |
164 |
184 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 26/35KV (Um{2}}KV)O'lchovli ma'lumotlar
|
Nom. Kesma maydoni |
|
Qurolsiz kabellar |
Po'lat simli zirhli kabellar |
||||||||||
|
Nom. Izolyatsiya qalinligi |
Mis lenta qalinligi |
Mis simli ekran maydoni* |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
Nom. To'shak qalinligi |
Zirh simining o'lchami |
Nom. Qopqoq qalinligi |
Taxminan Umumiy diametri |
Taxminan Og'irligi |
|||
|
Kun.k. |
AL |
CU |
AL |
||||||||||
|
mm% 5e2 |
mm |
mm |
mm% 5e2 |
mm |
mm |
kg/km |
mm |
mm |
mm |
mm |
kg/km |
||
|
50 |
10.5 |
0.1 |
16 |
2.1 |
38.3 |
1689 |
1402 |
1.2 |
2.5 |
2.5 |
46.8 |
2580 |
2395 |
|
70 |
10.5 |
0.1 |
16 |
2.2 |
40.2 |
1980 |
1564 |
1.2 |
2.5 |
2.5 |
48.8 |
2937 |
2611 |
|
95 |
10.5 |
0.1 |
16 |
2.2 |
41.8 |
2283 |
1714 |
1.2 |
2.5 |
2.6 |
50.9 |
3206 |
2737 |
|
120 |
10.5 |
0.1 |
16 |
2.3 |
43.4 |
2588 |
1871 |
1.4 |
2.5 |
2.6 |
51.5 |
3753 |
3177 |
|
150 |
10.5 |
0.1 |
25 |
2.3 |
44.9 |
2923 |
2028 |
1.4 |
2.5 |
2.7 |
53.8 |
4143 |
3371 |
|
185 |
10.5 |
0.1 |
25 |
2.4 |
47.3 |
3415 |
2281 |
1.4 |
2.5 |
2.7 |
55.6 |
4694 |
3693 |
|
240 |
10.5 |
0.1 |
25 |
2.5 |
49.5 |
3975 |
2542 |
1.4 |
2.5 |
2.8 |
57.6 |
5258 |
4005 |
|
300 |
10.5 |
0.1 |
25 |
2.5 |
51.9 |
4625 |
2822 |
1.4 |
2.5 |
2.9 |
60.8 |
5940 |
4301 |
|
400 |
10.5 |
0.1 |
35 |
2.6 |
54.9 |
5704 |
3288 |
1.6 |
2.5 |
3.0 |
63.6 |
7155 |
4894 |
*Ixtiyoriy simli ekran mis lentalar kombinatsiyasida taqdim etilishi mumkin. Jadvalda ko'rsatilganidek, nominal ekran maydoni standart sifatida taqdim etilishi mumkin.
Elektr ma'lumotlari
|
Nom. Kesma maydoni |
DC qarshilik CU / AL |
AC qarshilik CU / AL |
Supero'tkazuvchilarning qisqa tutashuvi reytingi CU / AL1 sek |
Imkoniyatlar |
Zaryadlash oqimi |
Mis simli ekranning qisqa tutashuvi reytingi 1 sek |
Mis lenta ekranining qisqa tutashuvi reytingi 1 sek |
Reaktivlik |
Induktivlik |
Empedans |
|||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
Trefoil |
Yassi oraliq |
||||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
||||||||||||
|
mm% 5e2 |
μΩ/m |
μΩm |
KA |
pF% 2fm |
mA% 2fm |
KA |
KA |
μΩ/m |
nH% 2fm |
μΩ/ m |
μΩ/ m |
||||
|
50 |
387/641 |
494/822 |
6.8/4.4 |
126 |
0.95 |
2.6 |
1.2 |
161 |
227 |
510 |
720 |
511 |
834 |
527 |
844 |
|
70 |
268/443 |
343/568 |
9.8/6.3 |
138 |
1.04 |
2.6 |
1.2 |
154 |
207 |
490 |
660 |
364 |
583 |
386 |
597 |
|
95 |
193/320 |
248/410 |
13.3/8.5 |
151 |
1.13 |
2.6 |
1.3 |
147 |
202 |
470 |
640 |
272 |
427 |
300 |
446 |
|
120 |
153/253 |
196/325 |
17.2/11.0 |
161 |
1.24 |
2.6 |
1.3 |
142 |
194 |
450 |
620 |
225 |
345 |
257 |
367 |
|
150 |
124/206 |
159/265 |
21.2/13.5 |
169 |
1.36 |
4.3 |
1.4 |
136 |
188 |
430 |
600 |
193 |
287 |
229 |
313 |
|
185 |
99.1/164 |
128/211 |
26.6/17.0 |
176 |
1.40 |
4.3 |
1.4 |
128 |
188 |
410 |
600 |
165 |
237 |
206 |
267 |
|
240 |
75.4/125 |
98/161 |
34.9/22.3 |
192 |
1.51 |
4.3 |
1.5 |
128 |
183 |
400 |
580 |
140 |
191 |
185 |
226 |
|
300 |
60.1/100 |
80/130 |
43.8/28.0 |
209 |
1.64 |
4.3 |
1.6 |
119 |
180 |
380 |
570 |
126 |
163 |
174 |
203 |
|
400 |
47.0/77.8 |
64/102 |
57.3/36.6 |
227 |
1.80 |
5.8 |
1.7 |
114 |
170 |
360 |
540 |
113 |
141 |
164 |
184 |
* Kapasitans va zaryadlash oqimi qiymatlari uchun EPR izolyatsiyalangan kabellar uchun ko'rsatilgan qiymatlarni 1,2 ga ko'paytiring.
Bir yadroli 1,8/3KV(Um=3,6KV) dan 26/35KV(Um=42KV) XLPE izolyatsiyasi uchun joriy reyting
|
Nom. Kesma maydoni |
To'g'ridan-to'g'ri erga dafn etilgan |
Bir tomonlama kanalga yotqizilgan |
Havoga yotqizilgan |
|||||||||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi teginish |
Trefoil |
Yassi teginish |
Yassi oraliq |
||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
AL |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
|
|
mm% 5e2 |
A |
A |
A |
A |
A |
A |
A |
|||||||
|
10 |
84 |
59 |
87 |
62 |
78 |
55 |
98 |
56 |
103 |
75 |
106 |
77 |
122 |
88 |
|
16 |
109 |
84 |
113 |
88 |
103 |
80 |
104 |
81 |
125 |
97 |
128 |
99 |
150 |
116 |
|
25 |
140 |
108 |
144 |
112 |
132 |
102 |
133 |
103 |
163 |
127 |
167 |
130 |
196 |
153 |
|
35 |
166 |
129 |
172 |
134 |
157 |
122 |
159 |
123 |
198 |
154 |
203 |
157 |
238 |
185 |
|
50 |
196 |
152 |
203 |
157 |
186 |
144 |
188 |
146 |
238 |
184 |
243 |
189 |
286 |
222 |
|
70 |
239 |
186 |
246 |
192 |
227 |
176 |
229 |
178 |
296 |
230 |
303 |
236 |
356 |
278 |
|
95 |
285 |
221 |
293 |
229 |
271 |
210 |
274 |
213 |
361 |
280 |
369 |
287 |
434 |
338 |
|
120 |
323 |
252 |
332 |
260 |
308 |
240 |
311 |
242 |
417 |
324 |
426 |
332 |
500 |
391 |
|
150 |
361 |
281 |
366 |
288 |
343 |
267 |
347 |
271 |
473 |
368 |
481 |
376 |
559 |
440 |
|
185 |
406 |
317 |
410 |
324 |
387 |
303 |
391 |
307 |
543 |
424 |
550 |
432 |
637 |
504 |
|
240 |
469 |
367 |
470 |
373 |
447 |
351 |
453 |
356 |
641 |
502 |
647 |
511 |
745 |
593 |
|
300 |
526 |
414 |
524 |
419 |
504 |
397 |
510 |
402 |
735 |
577 |
739 |
586 |
846 |
677 |
|
400 |
590 |
470 |
572 |
466 |
564 |
451 |
571 |
457 |
845 |
673 |
837 |
676 |
938 |
769 |
|
500 |
650 |
530 |
672 |
546 |
604 |
504 |
661 |
537 |
935 |
773 |
938 |
776 |
1118 |
919 |
|
630 |
700 |
600 |
882 |
646 |
654 |
554 |
771 |
617 |
1045 |
883 |
1048 |
886 |
1318 |
1089 |
|
800 |
750 |
660 |
1002 |
756 |
694 |
594 |
871 |
717 |
1145 |
983 |
1148 |
986 |
1528 |
1279 |
|
1000 |
800 |
720 |
1112 |
856 |
724 |
644 |
971 |
807 |
1235 |
1083 |
1238 |
1086 |
1738 |
1469 |
Bir yadroli 1.8/3KV (Um=3.6KV) dan 26/35KV (Um=42KV) gacha boʻlgan EPR izolyatsiyasi uchun joriy reyting
|
Nom. Kesma maydoni |
To'g'ridan-to'g'ri erga dafn etilgan |
Bir tomonlama kanalga yotqizilgan |
Havoga yotqizilgan |
|||||||||||
|
Trefoil |
Yassi oraliq |
Trefoil |
Yassi teginish |
Trefoil |
Yassi teginish |
Yassi oraliq |
||||||||
|
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
Kun.k. |
Al |
|
|
mm% 5e2 |
A |
A |
A |
A |
A |
A |
A |
|||||||
|
10 |
81 |
57 |
83 |
58 |
74 |
52 |
94 |
53 |
94 |
68 |
97 |
70 |
110 |
79 |
|
16 |
106 |
82 |
109 |
84 |
99 |
77 |
100 |
78 |
116 |
90 |
119 |
92 |
138 |
107 |
|
25 |
136 |
105 |
140 |
109 |
128 |
99 |
129 |
100 |
153 |
119 |
156 |
121 |
181 |
141 |
|
35 |
162 |
126 |
167 |
130 |
153 |
118 |
154 |
120 |
186 |
144 |
190 |
147 |
221 |
171 |
|
50 |
192 |
149 |
198 |
153 |
181 |
140 |
183 |
142 |
224 |
174 |
229 |
178 |
266 |
207 |
|
70 |
234 |
182 |
242 |
188 |
222 |
172 |
224 |
174 |
280 |
218 |
287 |
223 |
334 |
259 |
|
95 |
280 |
217 |
289 |
224 |
266 |
206 |
269 |
208 |
343 |
266 |
352 |
273 |
409 |
317 |
|
120 |
319 |
247 |
329 |
256 |
303 |
235 |
306 |
238 |
398 |
309 |
407 |
317 |
474 |
368 |
|
150 |
357 |
277 |
369 |
287 |
341 |
264 |
344 |
267 |
454 |
352 |
465 |
361 |
540 |
419 |
|
185 |
403 |
314 |
417 |
325 |
386 |
300 |
390 |
303 |
522 |
406 |
534 |
417 |
621 |
484 |
|
240 |
467 |
364 |
484 |
377 |
449 |
350 |
454 |
354 |
619 |
483 |
634 |
495 |
736 |
575 |
|
300 |
526 |
411 |
545 |
426 |
509 |
397 |
515 |
401 |
712 |
556 |
728 |
570 |
843 |
659 |
|
400 |
597 |
471 |
618 |
487 |
580 |
456 |
588 |
462 |
825 |
651 |
843 |
667 |
977 |
770 |
|
500 |
657 |
531 |
718 |
567 |
620 |
509 |
678 |
542 |
915 |
751 |
849 |
767 |
1157 |
920 |
|
630 |
707 |
601 |
928 |
667 |
670 |
559 |
788 |
622 |
1025 |
862 |
1054 |
876 |
1357 |
1090 |
|
800 |
757 |
661 |
1048 |
777 |
710 |
599 |
888 |
722 |
1125 |
961 |
1154 |
977 |
1567 |
1280 |
|
1000 |
807 |
721 |
1158 |
877 |
740 |
649 |
988 |
812 |
1215 |
1061 |
1244 |
1077 |
1777 |
1470 |
Joriy reyting shartlari
|
Tuproq harorati |
20 daraja |
|
Atrof-muhit harorati (havo) |
30 daraja |
|
Tuproq chuqurligi |
0.8m |
|
Tuproqning issiqlik qarshiligi |
1,5 Kom/Vt |
5. Ishlab chiqarishning borishi
6. Sertifikatlar:
 |
 |
7. Qadoqlash:
- Chelik yog'och baraban (fumigatsiya)
Har bir barabandagi kabel uzunligi: 1000m/2000m yoki haqiqiy kabel uzunligi talablariga muvofiq.
- Baraban hajmi:
Kabel uzunligi va konteyner o'lchamiga qarab
Sizga aniq narxni taklif qilish uchun bizga kerakli kabel uzunligi miqdorini ayting. Kattaroq miqdor, ko'proq chegirmali imtiyoz siz uchun tayyor!
- Yuk tashish porti:
Qingdao yoki sizning talablaringiz bo'yicha boshqa portlar.
-Dengiz yuklari:
FOB/C&F/CIF kotirovkalari mavjud.
 |
 |
 |
Issiq teglar: mv kabeli, Xitoy mv kabeli ishlab chiqaruvchilari, etkazib beruvchilari, zavodi
