1.Ilova (Olovga chidamli asboblar kabellari):
BS 5308 kabellari turli xil o'rnatish turlarida, shu jumladan neft-kimyo sanoatida mavjud bo'lgan aloqa va boshqaruv signallarini tashish uchun mo'ljallangan. Signallar analog, ma'lumot yoki ovoz turi va bosim, yaqinlik va mikrofon kabi turli xil transduserlardan bo'lishi mumkin. 1-qism 3-toifa kabellar odatda ko'proq mexanik va kimyoviy himoya talab qilinadigan yoki tegishli chuqurlikda to'g'ridan-to'g'ri ko'milishi kerak bo'lgan joylarda ishlab chiqilgan. Assortimentda jamoaviy va alohida ekranlangan juftliklar mavjud. Yong'in, tutun chiqarish va zaharli tutun hayot va jihozlar uchun potentsial xavf tug'diradigan qurilmalar uchun.
2.Standartlar(Olovga chidamli asboblar kabellari):
IEC 60332, BS5308
3.Kabel qurilishi(Olovga chidamli asboblar kabellari):
Dirijyor
BS EN 60228 bo'yicha 1-sinf qattiq mis o'tkazgich
BS EN 60228 bo'yicha 2-sinf simli mis o'tkazgich BS EN 60228 bo'yicha 5-sinf moslashuvchan mis o'tkazgich
Izolyatsiya
XLPE turi 03
Birlashtiruvchi lenta
PET (Polyester lenta)
Ekran
AL/PET (alyuminiy/Polyester lenta)
Drenaj simi
Qalaylangan mis
Choyshablar
LSZH (Low Smoke Zero Halogen) LTS3 turiga muvofiq. BS 7655 ga
Qoplash
Qo'rg'oshin yoki poliamid qoplamasi
Ichki qoplama
LSZH (Low Smoke Zero Halogen) LTS3 turiga muvofiq. BS 7655 ga
Qurol
Galvanizli po'lat simlar
Tashqi qoplama
LSZH (Low Smoke Zero Halogen) LTS3 turiga muvofiq. BS 7655 ga
4.Kabel parametrlari(Olovga chidamli asboblar kabellari):
Supero'tkazuvchilar kesimi (kv.mm) | Dirijyor sinfi | Iplar soni/Maks. Ip diametri (mm) | Maks. DC o'tkazgichning qarshiligi * 20 daraja (Ō/km) | Maks.L/R nisbati (mH/Ō) | Min. Izolyatsiyaga qarshilik (GŌ x sm) | Maks. O'zaro sig'im (nF/km) | Maks.Induktivlik (mH/km) | Test kuchlanish Vrms (yadro-yadro) | Test kuchlanish Vrms (asosiy ekran) |
0.5 | 2 | 7/0.3 | 36 | 25 | 20 | 250 | 1 | 2000 | 2000 |
0.5 | 5 | 16/0.2 | 39 | 25 | 20 | 250 | 1 | 2000 | 2000 |
0.75 | 2 | 7/0.37 | 24.5 | 25 | 20 | 250 | 1 | 2000 | 2000 |
0.75 | 5 | 24/0.2 | 26 | 25 | 20 | 250 | 1 | 2000 | 2000 |
1 | 2 | 7/0.43 | 18.1 | 25 | 20 | 250 | 1 | 2000 | 2000 |
1 | 5 | 32/0.2 | 19.5 | 25 | 20 | 250 | 1 | 2000 | 2000 |
1.5 | 2 | 7/0.53 | 12.1 | 40 | 20 | 250 | 1 | 2000 | 2000 |
2.5 | 2 | 7/0.67 | 7.41 | 60 | 20 | 250 | 1 | 2000 | 2000 |
Juftlar soni va kesma maydoni (kv. mm) | Min. Izolyatsiya qalinligi (mm) | Nominal qobiq qalinligi (mm) | Taxminan Kabel diametri (mm) | Taxminan Kabelning og'irligi (kg/km) | |
5-sinf dirijyor | 1 x 2 x 0.5 | 0.44 | 1 | 6.4 | 48.2 |
2 x 2 x 0.5 | 0.44 | 1 | 7.7 | 74.2 | |
3 x 2 x 0.5 | 0.44 | 1.1 | 9 | 100.8 | |
4 x 2 x 0.5 | 0.44 | 1.1 | 10.1 | 126.5 | |
5 x 2 x 0.5 | 0.44 | 1.2 | 11.1 | 151.8 | |
8 x 2 x 0.5 | 0.44 | 1.3 | 13.6 | 225.5 | |
10 x 2 x 0.5 | 0.44 | 1.3 | 15 | 274 | |
12 x 2 x 0.5 | 0.44 | 1.4 | 16.2 | 321.9 | |
16 x 2 x 0.5 | 0.44 | 1.4 | 18.4 | 416.1 | |
20 x 2 x 0.5 | 0.44 | 1.5 | 20.4 | 510 | |
24 x 2 x 0.5 | 0.44 | 1.6 | 22.2 | 603.1 | |
1 x 2 x 0.75 | 0.44 | 1 | 6.8 | 56.7 | |
2 x 2 x 0.75 | 0.44 | 1.1 | 8.3 | 89.5 | |
3 x 2 x 0.75 | 0.44 | 1.1 | 9.7 | 122.9 | |
4 x 2 x 0.75 | 0.44 | 1.2 | 10.9 | 155.8 | |
5 x 2 x 0.75 | 0.44 | 1.2 | 12 | 188 | |
8 x 2 x 0.75 | 0.44 | 1.3 | 14.7 | 282.2 | |
10 x 2 x 0.75 | 0.44 | 1.4 | 16.2 | 345 | |
12 x 2 x 0.75 | 0.44 | 1.4 | 17.6 | 406.3 | |
16 x 2 x 0.75 | 0.44 | 1.5 | 20 | 527.7 | |
20 x 2 x 0.75 | 0.44 | 1.6 | 22.2 | 649.5 | |
24 x 2 x 0.75 | 0.44 | 1.6 | 24.1 | 769 | |
1 x 2 x 1 | 0.44 | 1 | 7.1 | 64.1 | |
2 x 2 x 1 | 0.44 | 1.1 | 8.7 | 103.4 | |
3 x 2 x 1 | 0.44 | 1.1 | 10.2 | 143.1 | |
4 x 2 x 1 | 0.44 | 1.2 | 11.5 | 182.2 | |
5 x 2 x 1 | 0.44 | 1.2 | 12.6 | 220.5 | |
8 x 2 x 1 | 0.44 | 1.3 | 15.5 | 333.8 | |
10 x 2 x 1 | 0.44 | 1.4 | 17.1 | 408.9 | |
12 x 2 x 1 | 0.44 | 1.4 | 18.6 | 482.3 | |
16 x 2 x 1 | 0.44 | 1.5 | 21.2 | 629 | |
20 x 2 x 1 | 0.44 | 1.6 | 23.5 | 776.5 | |
24 x 2 x 1 | 0.44 | 1.7 | 25.5 | 920.3 | |
2-sinf dirijyor | 1 x 2 x 0.5 | 0.44 | 1 | 6.4 | 48 |
2 x 2 x 0.5 | 0.44 | 1 | 7.7 | 73.9 | |
3 x 2 x 0.5 | 0.44 | 1.1 | 9 | 100.4 | |
4 x 2 x 0.5 | 0.44 | 1.1 | 10.1 | 125.9 | |
5 x 2 x 0.5 | 0.44 | 1.2 | 11.1 | 151.2 | |
8 x 2 x 0.5 | 0.44 | 1.3 | 13.6 | 224.5 | |
10 x 2 x 0.5 | 0.44 | 1.3 | 15 | 272.7 | |
12 x 2 x 0.5 | 0.44 | 1.4 | 16.2 | 320.4 | |
16 x 2 x 0.5 | 0.44 | 1.4 | 18.4 | 414.1 | |
20 x 2 x 0.5 | 0.44 | 1.5 | 20.4 | 507.5 | |
24 x 2 x 0.5 | 0.44 | 1.6 | 22.2 | 600.1 | |
1 x 2 x 0.75 | 0.44 | 1 | 6.8 | 56.7 | |
2 x 2 x 0.75 | 0.44 | 1.1 | 8.3 | 89.5 | |
3 x 2 x 0.75 | 0.44 | 1.1 | 9.7 | 123.4 | |
4 x 2 x 0.75 | 0.44 | 1.2 | 10.9 | 155.9 | |
5 x 2 x 0.75 | 0.44 | 1.2 | 12 | 188 | |
8 x 2 x 0.75 | 0.44 | 1.3 | 14.7 | 282.4 | |
10 x 2 x 0.75 | 0.44 | 1.4 | 16.3 | 345.1 | |
12 x 2 x 0.75 | 0.44 | 1.4 | 17.6 | 406.4 | |
16 x 2 x 0.75 | 0.44 | 1.5 | 20.1 | 527.9 | |
20 x 2 x 0.75 | 0.44 | 1.6 | 22.2 | 649.7 | |
24 x 2 x 0.75 | 0.44 | 1.6 | 24.2 | 769.4 | |
1 x 2 x 1 | 0.44 | 1 | 7.2 | 65.2 | |
2 x 2 x 1 | 0.44 | 1.1 | 8.8 | 105.6 | |
3 x 2 x 1 | 0.44 | 1.1 | 10.4 | 146.7 | |
4 x 2 x 1 | 0.44 | 1.2 | 11.7 | 186.8 | |
5 x 2 x 1 | 0.44 | 1.2 | 12.9 | 226.1 | |
8 x 2 x 1 | 0.44 | 1.3 | 15.8 | 342.3 | |
10 x 2 x 1 | 0.44 | 1.4 | 17.4 | 419.3 | |
12 x 2 x 1 | 0.44 | 1.5 | 19 | 495.5 | |
16 x 2 x 1 | 0.44 | 1.6 | 21.6 | 646 | |
20 x 2 x 1 | 0.44 | 1.6 | 23.9 | 796.2 | |
24 x 2 x 1 | 0.44 | 1.7 | 26 | 945 | |
1 x 2 x 1.5 | 0.44 | 1 | 7.9 | 81.9 | |
2 x 2 x 1.5 | 0.44 | 1.1 | 9.7 | 136.4 | |
3 x 2 x 1.5 | 0.44 | 1.2 | 11.5 | 191.5 | |
4 x 2 x 1.5 | 0.44 | 1.2 | 13 | 246 | |
5 x 2 x 1.5 | 0.44 | 1.3 | 14.3 | 299.7 | |
8 x 2 x 1.5 | 0.44 | 1.4 | 17.7 | 457.6 | |
10 x 2 x 1.5 | 0.44 | 1.5 | 19.5 | 563.2 | |
12 x 2 x 1.5 | 0.44 | 1.5 | 21.2 | 666.6 | |
16 x 2 x 1.5 | 0.44 | 1.6 | 24.2 | 872.3 | |
20 x 2 x 1.5 | 0.44 | 1.7 | 26.8 | 1079.7 | |
24 x 2 x 1.5 | 0.44 | 1.8 | 29.2 | 1283.9 | |
1 x 2 x 2.5 | 0.53 | 1.1 | 9.3 | 113.8 | |
2 x 2 x 2.5 | 0.53 | 1.2 | 11.5 | 195.3 | |
3 x 2 x 2.5 | 0.53 | 1.3 | 13.6 | 278.3 | |
4 x 2 x 2.5 | 0.53 | 1.3 | 15.5 | 360.2 | |
5 x 2 x 2.5 | 0.53 | 1.4 | 17.1 | 441.1 | |
8 x 2 x 2.5 | 0.53 | 1.5 | 21.1 | 680.6 | |
10 x 2 x 2.5 | 0.53 | 1.6 | 23.4 | 840.3 | |
12 x 2 x 2.5 | 0.53 | 1.7 | 25.5 | 998.3 | |
16 x 2 x 2.5 | 0.53 | 1.8 | 29.1 | 1310.9 | |
20 x 2 x 2.5 | 0.53 | 1.9 | 32.3 | 1627.1 | |
24 x 2 x 2.5 | 0.53 | 2.1 | 35.2 | 1938.7 |
5.Paket: Yog'och barabanlarni eksport qilish (yong'inga chidamli asboblar kabellari):
